Vacuum Depalletizer

Used for depalletizing of empty aluminium -steel cans or bottles in order to feed the processing line. Cans/jars pallet, placed on infeed chain conveyor by fork-lift operator is driven ahead after setting layer # of pallet and pressing the start button by the operator. When the pallet is positioned inside the by sensors, a vacuum plate lifts up the first layer and carries it to side accumulation conveyor where the cycle is controlled thru sensors. After the first layer is evacuated then the cycle repeats for preset layer # times. When the final layer is evacuated, empty pallet is driven out on the same axis fm elevating booth to pallet stacker. System is supplied w/2 chain conveyors, empty pallet stacker, plastic segment belt accumulation conveyor. All process is controlled thru plc w/7" touchscreen display. Main construction (120x120x4mm) made of anti corrosive painted st.37 quality mild steel, cans/jars contact surfaces are made of aisi 304 quality stainless steel or low friction plastic components. Designed & build according ce(eu confirmity) safety standarts ...

PLEASE CONTACT BIGTEM FOR FURTHER INFORMATION...
